What is the role and working principle of thrust bearings in machinery?

The role of thrust bearings in machinery

Bear axial load: Thrust bearings are mainly used to bear axial force, that is, load along the axis direction. They are used to prevent axial movement or displacement, thereby ensuring that rotating parts operate within a fixed position.

Reduce friction and wear: By using rolling elements (such as balls or rollers), thrust bearings can significantly reduce friction and wear between rotating parts, increasing machine efficiency and service life.

Improve stability: Thrust bearings can stabilize rotating parts and prevent vibration and displacement due to axial force, thereby improving the smoothness and accuracy of equipment operation.

Separating and supporting rotating parts: They help separate and support rotating parts to maintain stable operation under high loads and speeds.

working principle

The working principle of thrust bearings mainly relies on the interaction between rolling elements and rings to bear axial loads and reduce friction. Here's how it basically works:

The role of rolling elements: The interior of a thrust bearing is usually composed of multiple rolling elements (such as balls, rollers, needles), which are located between the inner ring and the outer ring. When the bearing is subjected to axial load, the rolling elements roll between the inner ring and the outer ring, changing the friction from sliding friction to rolling friction, thereby reducing friction and wear.

Inner and outer rings: The inner and outer rings of thrust bearings are designed to accommodate the movement of the rolling elements. The inner ring is usually fixed on the rotating shaft, and the outer ring is fixed on the bearing seat or frame. When the bearing is subjected to axial load, the load is transmitted between the inner ring and the outer ring through the rolling elements.

The function of the cage: The cage is used to evenly distribute the rolling elements between the inner ring and the outer ring to prevent mutual contact and collision between the rolling elements. The cage can also guide the movement of the rolling elements to ensure that they roll on the correct track.

Lubrication: Thrust bearings require lubrication during operation to reduce friction and wear. The lubricant can be grease or lubricating oil, which reduces the direct contact between the rolling elements and the rings by forming an oil film, further reducing friction and wear.
